CSM050LA اریجینال-کیفیت بسیار بالا

CSM050LA
ترانسدیوسر(سنسور جریان اثر هال) 50 آمپر AC/DC - Hall-Effect Current Sensor Series Current Transducers ساخت چیفول
تعداد
تخفیف
قیمت
+1
518,100 تومان
+5
5.0 %
492,200 تومان
+20
10.3 %
464,800 تومان
+50
15.1 %
440,000 تومان
توجه: حداقل تعداد خرید این محصول 1 عدد می باشد.

نقد و بررسی اجمالی

ترانسدیوسر(سنسور جریان اثر هال) 50 آمپر AC/DC - Hall-Effect Current Sensor Series Current Transducers ساخت چیفول



 دریافت دیتا شیت

ترانسدیوسر(سنسور جریان اثر هال) 50 آمپر   AC/DC
Current Transducers
ساخت چیفول

Current Transducer CSM050LA
For the electronic measurement of currents : DC, AC, pulsed...,
with a galvanic isolation between the primary circuit (high power)
and the secondary circuit (electronic circuit).

 Hall-Effect Current Sensor Series


Product Attributes Select All
Categories
Manufacturer CHIEFUL
Series LA
Packaging ? Bulk ?
Part Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Closed Loop
Current - Sensing 50A
Number of Channels 1
Output Ratiometric, Current
Sensitivity -
Frequency DC ~ 200kHz
Linearity ±0.15%
Accuracy ±0.65%
Voltage - Supply ±12 V ~ 15 V
Response Time 1µs
Current - Supply (Max) 60mA
Operating Temperature -40°C ~ 85°C
Polarization Bidirectional
Mounting Type Through Hole
Package / Case

Module, Single Pass Through


ترانسدیوسر Transducers
بسیار با دوام و با کیفیت
طول عمر بالا
 انواع اینورترهای دور و جریان
انواع محافظ های تابلو برق

انواع دستگاه های جوش و برش اینورتری
انواع نمایشگرهای جریان
مصارف عمومی
مخابراتی
نظامی و غیره ...


مشخصات:

مشخصات - پارامترها

مقادیر

خانواده

ترانسدیوسر- مبدل پارامتر

سری

اندازه گیری جریان

تعداد پین

3

پکیج

-

 ولتاژ کاری

±12V

جریان کاری

50A

IPN

50A

IP

-

VOUT

-

VC

±12V

IC

I<60mA

TR-tr

T≤1µs

TA

85+~40-

TS

150+~55-

ابعاد

29.2x25.4x17.8mm

دمای کاری

150+~55-

برند

CHIEFUL

کشور سازنده

-

کیفیت

اریجینال

نوع مونتاژ

DIP

ویژگی خاص

-

Features
·Closed loop (compensated) current
transducer using the Hall effect
·Printed circuit board mounting
·Insulated plastic case recognized
according to UL 94-V0.
Advantages
·Excellent accuracy
·Very good linearity
·Low temperature drift
·Optimized response time
·Wide frequency bandwidth
·No insertion losses
·High immunity to external
interference
·Current overload capability.
Applications
·AC variable speed drives and servo
motor drives
·Static converters for DC motor drives
·Battery supplied applications
·Uninterruptible Power Supplies
(UPS)
·Switched Mode Power Supplies
(SMPS)
·Power supplies for welding
applications.
