ماژول SX1278 ESP32 اورجینال

SX1278 ESP32/ESP32 LoRa 0.96 Inch Blue OLED Digital Display Bluetooth Bluetooth Kit Module
ماژول ESP32 به صورت فول با ال سی دی-وای فای و... ESP32 LoRa 0.96 Inch Blue OLED Digital Display Bluetooth WIFI Kit Module IOT Development Board 433MHz 470MHz ماژول توسعه یافته ESP32 با نمایشگر OLED
تعداد
تخفیف
قیمت
+1
639,400 تومان
+3
2.5 %
623,700 تومان
+5
4.4 %
611,100 تومان
توجه: حداقل تعداد خرید این محصول 1 عدد می باشد.

نقد و بررسی اجمالی

ماژول ESP32 به صورت فول با ال سی دی-وای فای و... ESP32 LoRa 0.96 Inch Blue OLED Digital Display Bluetooth WIFI Kit Module IOT Development Board 433MHz 470MHz ماژول توسعه یافته ESP32 با نمایشگر OLED



 دریافت دیتا شیت



Description
WIFI Kit series is the new development of the cost-effective networking program, the main chip using Lexin ESP32, Tensilica LX6 dual-core processor, clocked at 240MHz, computing power up to 600DMIPS, chip built-in 520 KB SRAM, 802.11 b / g / N HT40 Wi-Fi transceiver, baseband, protocol stack and LWIP, integrated dual-mode Bluetooth (traditional Bluetooth and BLE low power Bluetooth

This product is based on the WIFI Kit 32 added SX1278 chip, that is,  remote modem, 433MHz-470MHz frequency, about -148dBm high sensitivity, +20 dBm power output, high reliability, transmission distance measured open area communication distance 2.6Km

Onboard 32MByte Flash, Wi-Fi antenna, 0.96-inch blue OLED display, lithium battery charging circuit and interface, CP2102 USB to serial chip, the perfect support for Arduino development environment, can be very simple and fast for program verification and product development

Operating voltage: 3.3V to 7V
Operating temperature range: -40 ° C to + 90 ° C
Supports Sniffer, Station, softAP and Wi-Fi Direct modes
Data rate: 150 Mbps @ 11n HT40,72 Mbps @ 11n HT20,54 Mbps @ 11g, 11 Mbps @ 11b
Transmit power: 19.5 dBm @ 11b, 16.5 dBm @ 11g, 15.5 dBm @ 11n
Receiver sensitivity up to - 98 dBm
UDP continues to throughput by 135 Mbps

ESP32 OLED

ESP32 OLED 4
