ای سی لایه فیزیکی اترنت ،شبکه با سرعت10/100 مگابیت بر ثانیه که اینترفیس های SNI و RMII و MII را پشتیبانی میکند. PHYTER Commercial Temperature Single Port 10/100 Mb/s Ethernet Physical Layer Transceiver
Features
Low-power 3.3V, 0.18µm CMOS technology
Low power consumption < 270mW Typical
3.3V MAC Interface
Auto-MDIX for 10/100 Mb/s
Energy Detection Mode
25 MHz clock out
(SNI Interface (configurable
(RMII Rev. 1.2 Interface (configurable
(MII Serial Management Interface (MDC and MDIO
IEEE 802.3u MII
IEEE 802.3u Auto-Negotiation and Parallel Detection
IEEE 802.3u ENDEC, 10BASE-T transceivers and filters
IEEE 802.3u PCS, 100BASE-TX transceivers and filters
Integrated ANSI X3.263 compliant TP-PMD physical sublayer with adaptive equalization and Baseline
Wander compensation
Error-free Operation up to 137 meters
Programmable LED support Link, 10 /100 Mb/s Mode, Activity, and Collision Detect
Single register access for complete PHY status
(10/100Mb/s packet BIST (Built in Self Test
(48-pin LQFP package (7mm) x (7mm
